Housing
Matte natural anodized, aluminum extrusion profile and stainless steel mounting accessories with plastic end cap.
Optics
Acrylic transparent optical lens.
Led
High-efficacy mid power LED with CRI>80, achieving L70B50 ≥ 50,000 hours of lifetime.
Driver
24Vdc external type. Constant voltage output driver with high efficiency.
Dimensions
Light Distribution
Filter By
Technical Data
| Type Code | Power (w) | CCT (K) | Light Output (lm) | CRI | V/Hz | Weight (Kg) | Beam Angle | L (mm) | Files |
|---|---|---|---|---|---|---|---|---|---|
| SDDMD.300.15.30.55 | 15 | 3000 | 1080 | >80 | 24V DC | 0,30 | 9°/55° | 300 |
|
| SDDMD.300.15.40.55 | 15 | 4000 | 1160 | >80 | 24V DC | 0,30 | 9°/55° | 300 |
|
| SDDMD.600.30.30.55 | 30 | 3000 | 2160 | >80 | 24V DC | 0,60 | 9°/55° | 600 |
|
| SDDMD.600.30.40.55 | 30 | 4000 | 2320 | >80 | 24V DC | 0,60 | 9°/55° | 600 |
|
| SDDMD.900.45.30.55 | 45 | 3000 | 3240 | >80 | 24V DC | 0,90 | 9°/55° | 900 |
|
| SDDMD.900.45.40.55 | 45 | 4000 | 3480 | >80 | 24V DC | 0,90 | 9°/55° | 900 |
|
| SDDMD.1200.60.30.55 | 60 | 3000 | 4320 | >80 | 24V DC | 1,2 | 9°/55° | 1200 |
|
| SDDMD.1200.60.40.55 | 60 | 4000 | 4640 | >80 | 24V DC | 1,2 | 9°/55° | 1200 |
|
| SDDMD.1500.75.30.55 | 75 | 3000 | 5660 | >80 | 24V DC | 1,5 | 9°/55° | 1500 |
|
| SDDMD.1500.75.40.55 | 75 | 4000 | 6090 | >80 | 24V DC | 1,5 | 9°/55° | 1500 |
|
