Arlight works for correct lighting in all areas of life. Arlight thinks multi-dimensionally for our workplaces where we spend most of our time; focuses on comfort. Rail is designed especially for areas requiring low glare; It meets all requirements within the scope of occupational health and safety.
Light illuminates good ideas
It is necessary for the formation of the right idea and motivation.
directing the light towards
It allows you to see the truth...
As with every product of Arlight, Rail went through 35 different tests; It is fully functional. Rail was specially designed for the light comfort and occupational health of the space; It offers black and white reflector options.
Arlight, the choice of those who do their job right; It designs all workplace lights according to the space, not the standard. Rail is applied while preserving originality according to the different light options of each business line and each office. In the light of success, Rail combines stylish details with security; It changes the atmosphere of the work environment.
Housing
Sheet steel body with electrostatic powder coating.
Optics
Anti-glare reflector and 80° optical lens
Led
High-efficiency LED with CRI>80, achieving L90B50 ≥ 50,000 hours of lifetime.
Driver
Constant current output LED driver with high efficiency and Pf≥0.95
Options
1 or 3 hours emergency lighting kit
Dimming via DALI
Black and white color option for reflector
| Type Code | Power (w) | CCT (K) | Light Output (lm) | CRI | V/Hz | Weight (Kg) | Files |
|---|---|---|---|---|---|---|---|
| GRAL.6060.B.23.30 | 23 | 3000 | 2920 | >80 | 220-240/50-60 | 5,4 |
|
| GRAL.6060.B.23.40 | 23 | 4000 | 3110 | >80 | 220-240/50-60 | 5,4 |
|
| GRAL.6060.B.30.30 | 30 | 3000 | 3950 | >80 | 220-240/50-60 | 5,4 |
|
| GRAL.6060.B.30.40 | 30 | 4000 | 4200 | >80 | 220-240/50-60 | 5,4 |
|
| GRAL.6060.W.23.30 | 23 | 3000 | 3260 | >80 | 220-240/50-60 | 5,4 |
|
| GRAL.6060.W.23.40 | 23 | 4000 | 3460 | >80 | 220-240/50-60 | 5,4 |
|
| GRAL.6060.W.30.30 | 30 | 3000 | 4410 | >80 | 220-240/50-60 | 5,4 |
|
| GRAL.6060.W.30.40 | 30 | 4000 | 4700 | >80 | 220-240/50-60 | 5,4 |
|
