Housing
Sheet steel body with electrostatic powder coating.
Optics
Prismatic structured opal white diffuser with lambertian light distribution and high transmissivity.
Led
High-efficiency LED with CRI>80, achieving L90B50 ≥ 50,000 hours of lifetime.
Driver
Constant current output LED driver with high efficiency and Pf≥0.95
UGR (Glare)
36W : (4H-8H 70/50/20) <19,2
28W : (4H-8H 70/50/20) <19
Options
1 or 3 hours emergency lighting kit
Dimming via DALI
Color
Ral 9016
Ral 9006
Dimensions
Filter By
Technical Data
| Type Code | Power (w) | CCT (K) | Light Output (lm) | CRI | V/Hz | Weight (Kg) | Cut-out Size (mm) | Files |
|---|---|---|---|---|---|---|---|---|
| GMPT.6060.36.30 | 36 | 3000 | 3530 | >80 | 220-240/50-60 | 4 | 595x595 |
|
| GMPT.6060.36.40 | 36 | 4000 | 3750 | >80 | 220-240/50-60 | 4 | 595x595 |
|
| GMPT.6060.28.30 | 28 | 3000 | 2620 | >80 | 220-240/50-60 | 4 | 595x595 |
|
| GMPT.6060.28.40 | 28 | 4000 | 2790 | >80 | 220-240/50-60 | 4 | 595x595 |
|
